BXST BX-V105 Adjustable Voltage Protector (AVS30)

The BXST BX-V105 is engineered to shield your valuable appliances from voltage irregularities. Operating at 220V AC with a 30A capacity, it offers adjustable settings for both under and over-voltage cutoffs, ranging from 150–230V and 230–300V respectively. The device features a customizable delay time between 10 seconds to 10 minutes, ensuring stability before power restoration. Its built-in surge and spike protection further enhances appliance safety.

Features:

• Adjustable Voltage Thresholds: Set under-voltage between 150–230V and over-voltage between 230–300V.

• Customizable Delay Timer: Delay time adjustable from 10 seconds to 10 minutes.

• High Current Capacity: Supports up to 30A, suitable for heavy-duty appliances.

• Surge & Spike Protection: Integrated protection against voltage spikes.

• LED Indicators: Bright LEDs for clear status indication.

• Compact Design: Easy installation with a space-saving form factor.


  Specifications:

  • Model: BX-V105

  • Operating Voltage: 220V AC

  • Frequency: 50/60Hz

  • Current Capacity: 30A

  • Under-Voltage Cutoff: 150–230V (adjustable)

  • Over-Voltage Cutoff: 230–300V (adjustable)

  • Delay Time: 10 seconds to 10 minutes (adjustable)

  • Protection Features: Over-voltage, under-voltage, surge, and spike protection

  • Material: Flame-retardant ABS/PC/PA66

  • Operating Temperature: -5°C to +55°C

  • Humidity: ≤90% RH

  • Applications: Air conditioners, refrigerators, water heaters, and other large appliances
